Thermal Conductivity Electrical Ground Bus Bar / High Voltage
Busbar 10mm
Electrical Ground Bus Bar Application:
Electronic products, Children toys, Locks, Watches, Glasses, Baby
carriage, Bicycle, Kitchen appliances, cameras, printers, office
equipment, precision equipment and various kinds of vehicles
Regarding the production of Electrical Ground Bus Bar, in most
cases it is customized based on your drawings. If there is:
1) formal drawings, we'll quote for you very soon
2) draft drawings, we'll share our advice for you to finalize the
drawing before quote
3) just certain thoughts, our engineers will be able to make
drawings for your confirmation
Electrical Ground Bus Bar feature
High bonding strength.
Pure T2 copper.
Copper foil busbar to be used in transformer has a profile to allow
for transformer thermal expansion and contraction
Made of copper foil provides maximum flexibility and reduces
vibration . It is typically used for copper busbar systems,
transformer connections and High Voltage Switchgear.
Electrical Ground Bus Bar Details
| Item:Thermal Conductivity Electrical Ground Bus Bar / High Voltage
Busbar 10mm |
| Product Name: Oxygen-free copper |
| Thickness: 10mm |
| Width: 120mm |
| Length: 735mm |
| Feature: Thermal Conductivity |
| Finish: Plate with nickel |
Electrical Ground Bus Bar Technical Parameters:
| Thickness×Width (mm) | 1.5 -20× (15-500) |
| Copper content | 99.98% |
| Density (g/cm³) | 8.9 |
| Resistivity (Ωmm²/m) | 0.018 |
| Tensile Strength (MPa) | ≥250 |
Electrical Ground Bus Bar Conventional Types and Sizes:
| Types | Total Thickness | Thickness of copper | Width | Length | Weight(kg/m) |
| BG-1.0*550*650 | 1.0 | 0.3mm+0.3mm | 550 | 650 | 3.18 |
| BG-1.5*550*650 | 1.5 | 0.3mm+0.3mm | 550 | 650 | 4.77 |
| BG-2.0*220*460 | 2.0 | 0.3mm+0.3mm | 220 | 460 | 1.80 |
| BG-3.0*350*750 | 3.0 | 0.3mm+0.3mm | 350 | 750 | 7.01 |
| BG-4.0*270*1056 | 4.0 | 0.3mm+0.3mm | 270 | 1056 | 10.15 |
| BG-5.0*106*412 | 5.0 | 0.3mm+0.3mm | 106 | 412 | 1.94 |
| BG-8*80 | 8 | 0.3mm+0.3mm | 80mm | ≤6000mm | 34.176 |
| BG-10*100 | 10 | 0.3mm+0.3mm | 100mm | ≤6000mm | 53.4 |
| BG-12*120 | 12 | 0.3mm+0.3mm | 120mm | ≤6000mm | 76.896 |
| Others | | | As request | | |
FAQ
Q1.Are you factory?
A.Yes,we are factory for copper and aluminum bus bars since year of
2012.You are welcome to visit our factory at your convenient time.
Q1. What is your terms of packing?
A: Generally, we pack our goods in neutral white boxes and brown
cartons. If you have legally registered patent,
we can pack the goods in your branded boxes after getting your
authorization letters.
Q2. What is your terms of payment?
A: T/T 30% as deposit, and 70% before delivery. We'll show you the
photos of the products and packages
before you pay the balance.
Electrical Ground Bus Bar Show
